Drone was developed by Bell Aircraft and redesignated to F7F-3K under a Navy contract during 1945-1946. The ircraft crashed at MCAS Cherry Point, NC after the final demonstration flight on 8 August 1946.





Specifications F7F-3K
General

Type: Drone
Crew: 2
First flight: 2 November 1943
Number built: 1, 364 (all type)
Powerplant
2 × Pratt & Whitney R-2800-34W Double Wasp radial |
2100 hp each | Pistons
Dimensions/Masses
Length: 13.8 m | Wingspan: 15.7 m | Height: 5.1 m
Wing area: 42.3 m² | Empty weight: 7380 kg
Loaded weight: ? kg | Max takeoff weight: 11670 kg
Performances
Maximum speed: 740 km/h | Range: 1900 km
Service ceiling: 12300 m
Armament

Inside: -
Outside: -
