194 GPF in road configuration with its tracked prime mover and ammunition carrier. Off-road, the traction bar was replaced by a cable and the distance between the two vehicles was extended to avoid the risk of damage caused by rough terrain. The 28-ton prime mover, powered by a 120 hp Panhard engine, could carry up to 3 tonnes of ammunition (here 30 rounds). |
Specifications |
| General |
Type:
Self-Propelled Artillery |
| Engine |
| Panhard SUK4 M2 | 120 hp |
| Dimensions/Masses |
| Length: 7.77 m | Width:
2.54 m | Height: 3.05 m Weight: ? kg | Max. Combat Weight: 29600 kg Elevation: +0 to +35° | Traverse: 55° Rounds weight: 80.9 / 78.9 / 83.5 kg. |
| Performances |
| Fire rate: 1 rpm |
Muzzle Velocity: 735 m/s | Fire Range: 18000 m - 20800 m | Road Speed: 8-10 km/h |
