Light Export Tank - Iranian army. |
| General |
Type:
Light Tank |
| Engine |
| 6-cylinder, water-cooled Praga RHP Gasoline | 55 hp |
| Dimensions/Masses |
| Length: 3.20m | Width:
1.73 m | Height: 1.67m Weight: 3900 kg |
| Armor |
| Maximum: 12 mm - Minimum: 6 mm |
| Performances |
| Max. Speed:
45km/h | Power/weight: 14.1 hp/t | Range:
170 km Suspension: leaf spring bogie |
| Armament |
Main:
1 x 7.92 millimetres (0.312 in) ZB vz.35 or vz.37 MG |
