Legion Condor - Spain, 1936.







VJ/88, Legion Condor - Tablada, Spain, 1937.







2.J/88, Legion Condor - One of the first production Bf.109s, which were sent to Spain in March 1937.







2.J/88, Legion Condor - Alar d'el Rey, July 1937.









Circa 1939.



Me Bf109B Specifications
General

Type: Fighter
Crew: 1
Engine
Junkers Jumo 210D V12 | 635 hp | Pistons
Dimensions/Masses
Length: 8.51 m | Width: 9.87 m | Height: 2.59 m
Weight: 1582 kg | Max. Combat Weight: 2296 kg
Performances
Max. Speed: 470 km/h | Ceiling: 8400 m | Range: 560 km
Armament

MG: 2-4 x 7.92 mm MG 17
Bombs: -









J/88, Legion Condor - Gptm. Schellman (12 victories). Spring 1938. Only 5 Bf.109C were delivered to Spain.









2.J/88, Legion Condor - Gotthard Handrick (5 victories). 18 June 1937 - 10 September 1938.





Me Bf109C/D Specifications
General

Type: Fighter
Crew: 1
Engine
Junkers Jumo 210D V12 | 635 hp | Pistons
Dimensions/Masses
Length: 8.51 m | Width: 9.87 m | Height: 2.59 m
Weight: 1582 kg | Max. Combat Weight: 2296 kg
Performances
Max. Speed: 470 km/h | Ceiling: 8400 m | Range: 560 km
Armament

MG: 4 x 7.92 mm MG 17
Bombs: -
