Specifications C-47B
General

Type: Transport
Crew: 3 + 28 troops or 6000 kg of payload
First flight: 23 December 1941
Introduction: 1946 for Belgian Air Force
Number built: ?
Powerplant
2 × Pratt & Whitney R-1830-90C | 1200 hp | Pistons
Dimensions/Masses
Length: 19.43 m | Wingspan: 29.41 m | Height: 5.18 m
Wing area: 18.22 m²
Empty weight: 8226 kg | Max takeoff weight: 14061 kg
Performances
Maximum speed: 360 km/h
Combat radius: 2575 km | Ferry range: 5795 km
Service ceiling: 8045 m
Armament

Inside: -
Outside: -
