1st: standard model
2nd: Stab.IV/NJG 5 - Leipheim, early 1943 (FuG 202 Lichtenstein BC)
3rd: Stab.IV/NJG 5 - Kursk area, Summer 1943 (FuG 212 Lichtenstein C-1)
4th: heavy fighter with FuG 220 Lichtenstein SN2
5th: heavy fighter with FuG 227 Flensburg (the canopy of the nose is factitious (painted)
6th: 3./NJG 4 - Maing-Finthon, Germany, March 1944 (FuG 220 Lichtenstein SN2)



Ju-88C-6 Specifications
General

Type: Heavy Night Fighter
Crew: 4
Engine
2 x Junkers Jumo 211 J V12 | 1410 hp | Pistons
Dimensions/Masses
Length: 14,36 m| Width: 20,08 m | Height: 5.05 m
Weight: ? kg | Max. Combat Weight: 12332 kg
Performances
Max. Speed: 494 km/h | Ceiling: 9900 m | Range: 1050 km
Armament

MG: 3 x 20 mm MG FF/M gun, 3 x 7.92 mm MG17,
1 x 7.92 mm MG81Z (double) or 1 x 13 mm MG 131
optional 2 x 20 mm MG 151/20
Radar: depend of version
