The General Estienne launched in 1921 a study of the future battle tank and called on the manufacturers who have already participated in the production of tanks during the conflict that has just ended. Five prototypes were presented in 1924: SRA, FCM 21, Famh, Delaunay-Belleville and SRB or Renault-Schneider Type B.

None of these prototypes will be adopted. However, the experience acquired makes it possible to define the specifications of the future tank B and these devices are at the origin of the Dual tank, a concept which will be followed until the beginning of the Second World War.

Specifications

Type: Battle tank
Crew: 3 men (Commander/turret gunner, driver/gunner, loader)

Renault six-cylinder | 180 hp at 1500 rpm
Dimensions/Masses
Length: 5.95 m | Width: 2.49 m | Height: 2.26 m
Ground Clearance: 0.40 m | Weight: 19000 kg
Fuel Capacity: 420 L
Mobility
Maximum speed: 17.5 km/h | Range: 140 km
Trench Crossing:
2.50 m | Suspension: Leaf springs
Armament
Main armament: 1 hull-mounted 75 mm howitzer
Secondary armament:
2 x turret-mounted Hotchkiss mle 1914
8 mm machine guns
Armor:
30mm maximum
