This record plane equipped with a DB.601A engine participated in the Zurich meeting in July-August 1937.






This record plane equipped with a DB.601 Rennmotor II racing engine, participated in the Zurich meeting in July-August 1937.
Piloted by Generalmajor Udet.






Group of misinformation of enemy. Winter 1938.









III/JG 52 - Hopstadten, Germany, August 1940.





Me Bf109E-1 Specifications

Type: Fighter
Crew: 1

Daimler Benz DB 601Aa 12-cylinder, inverted Vee, liquid-cooled 1175 hp | Pistons
Dimensions/Masses
Length: 8.64m | Width: 9.87m | Height: 2.50m
Weight: ? kg | Max. Combat Weight: 1975 kg
Performances
Max. Speed: 570 km/h | Ceiling: 10972 m | Range: 660 km
Armament

MG: 2 x 20mm MG FF guns & 2 x 7.92mm MG-17
Bombs: -



Data
